Antec Signature 1300 Platinum SMPS 1300 Watt 80 Plus Platinum Fully Modular PSU
, ,

Antec Signature 1300 Platinum SMPS 1300 Watt 80 Plus Platinum Fully Modular PSU

Availability:

99999999 in stock
Compare

Antec Signature 1300 Platinum SMPS 1300 Watt 80 Plus Platinum Fully Modular PSU

₹23,480.00

99999999 in stock

Compare

Antec Signature 1300 Platinum Power Supply Unit



Equipped with superior features that ensure peak performance for the enthusiast and gaming-oriented segment, the Signature power supply Series boasts unparalleled stability and 80 PLUS® Platinum-certified efficiencies. Advanced thermal control with the Zero RPM mode enables the optimal balance between silence and cooling. The CircuitShield™ suite of industrial-grade protections ensures that the power delivered to your system is safe and reliable in any environment. Signature Series are a great choice for a reliable and efficient PC system for gamers and professionals.


FDB 135mm
Silent Fan
Featuring whisper-quiet, fluid dynamic bearing 135mm fan provides high airflow with durability and longevity.


100% Top-Grade Japanese Capacitors
Achieve unprecedented tight voltage regulation & low ripple
& noise to maximize your system’s performance.



Antec Signature 1300 Platinum SPECIFICATIONS :



Model X8000A506-18
Type ATX
Modular Fully
Dimension (W x L x H) 150 x 170 x 86mm
Warranty 10 years
Input Voltage 100-240
Input Current 15A ~ 7.5A
Input Frequency Range 47Hz ~ 63Hz
PFC APFC
PFC at half / full load:
> 0.95 at AC 110v 60Hz(typical)
> 0.90 at AC 230v 50Hz(typical)
Power Good Signal 100 ~ 500mS
Efficiency At 20% / 50% / 100% load AC 115V internal,
the power efficiency should be at least 90% / 92% / 89%.
Protection OCP / OVP / UVP / SCP / OPP / OTP / SIP / NLO
Output Capacity 1300W
Operation Temperature 0 ~ 40°C
Regulatory CB, CE, FCC, BSMI, TUV, cTUVus, 3C, KC, RCM
Fan 135 x 135 x 25(mm) FDB Silent Fan
Certifications 80 Plus Platinum
Connector 1 x MB 24(20+4) Pin
2 x 8(4+4) Pin EPS 12V
12 x 8(6+2) Pin PCI-E
14 x SATA
5 x Molex
1 x FDD
UPC# 0-761345-11705-0 SP1300
0-761345-11706-7 SP1300 AU
0-761345-11707-4 SP1300 EC
0-761345-11708-1 SP1300 GB
0-761345-11709-8 SP1300 JP
Net Weight 2.12 Kgs
Gross Weight 4.05 Kgs
SKU: X8000A506-18 Categories: , ,
